Cost effective – FlexLock can provide significant cost savings compared to non-locking couplings with a harnessing system.
Restrains pressure thrusts without thrust blocks at bends.
Convert cut lengths of pipe into flanged pipes – allows use of pipe offcuts.
For gas applications a working pressure of 6 bar can be achieved.
Flange Adaptor Body Options:
Ductile Iron to BS EN 1563 EN-GJS-450-10
Mild Steel to: BS EN 10025: Grade S275
Gasket: EPDM compound Grade E to BS EN 681-1
Nitrile compound Grade ‘G’ to BS EN 682-1
FlexLock permits angular deflection between pipes, allowing for normal pipeline movement such as ground settlement. Long radius curves can also be accommodated, reducing the need for special fittings. FlexLock couplings allow for a total angular deflection of ±6° (±3° for flange adaptors).
The ability to provide angular deflection in ANY plane is a particular advantage – a harness assembly can provide angular deflection only in ONE plane.
The Product Data tables are filterable and searchable to help you find the products you are looking for faster.
Just click the column header that you want to filter or sort by. Then click
to add a product to the enquiry basket.
|
Part Number A to Z Z to A Select All CT2900 CT2901 CT2902 CT2903 CT2904 CT2905 CT2913 CT2914 CT2915 |
Nominal Size (mm) A to Z Z to A Select All 50 65 80 100 150 200 250 300 |
Nominal Size (inches) A to Z Z to A Select All 10" 12" 2 1/2" 2" 3" 4" 6" 8" |
Flange A to Z Z to A Select All 50 65 80 100 150 200 250 300 |
Flange Type A to Z Z to A Select All PN10/16 PN16 |
Steel Ø Min. A to Z Z to A Select All 60.3 76.1 88.9 114.3 165.1 168.3 219.1 273 323.9 |
Enquiry |
|---|---|---|---|---|---|---|
| CT2900 | 50 | 2" | 50 | PN10/16 | 60.3 | |
| CT2915 | 65 | 2 1/2" | 65 | PN10/16 | 76.1 | |
| CT2901 | 80 | 3" | 80 | PN10/16 | 88.9 | |
| CT2902 | 100 | 4" | 100 | PN10/16 | 114.3 | |
| CT2903 | 150 | 6" | 150 | PN10/16 | 165.1 | |
| CT2904 | 150 | 6" | 150 | PN10/16 | 168.3 | |
| CT2905 | 200 | 8" | 200 | PN16 | 219.1 | |
| CT2913 | 250 | 10" | 250 | PN10/16 | 273 | |
| CT2914 | 300 | 12" | 300 | PN10/16 | 323.9 |
